Low - Power Safety Light Curtains with High Dielectric Strength and
Anti - Interference Features
Safety Light Curtains
We provide professional Safety Light Curtains, support the
conveying of various types of bottles, and provide a variety of
conveying types.
The Safety Light Curtains, also known as infrared safety light
barriers or safety optical sensors, are advanced safety devices
designed to provide reliable protection against unauthorized access
to hazardous areas in industrial environments. These curtains
detect the presence of objects or individuals by emitting and
receiving infrared beams, thereby preventing accidents and ensuring
compliance with safety standards
PRODUCT PARAMENTERS
Product name | security light curtain/infrared safety light barrier/safety optical
sensor |
Protective height | 60-1150mm(Universal) |
Beam gap | 10/20/30/40mm |
Resolution | 15/25/35/45mm |
Beams | 4,6,8,10,12 |
Protective distance | 05:5m,10:10m,15:15m,25:25m,30:30m |
Output current | <=200mA |
Power | <5W |
Output signal | NPN/PNP |
Response time | <5ms |
Cross-section | 30*30mm |
Operating voltage | DC10-DC32V |
Light curtain form | Through-Beam |
Dielectric strength | AC1500V.60S.No breakdown or flicker |
Work Ambient humidity | Relative humidity at 20 ℃ <85% |
Anti-light interference | Incidence Angle>5° |
Shell protection class | IP65 |
*It can be modified according to customer requirements.
Please click the form below to download and fill it out to inquire
about detailed specifications and parameter options.
PRODUCT ADVANTAGE
*The Safety Light Curtains offer non-contact protection, avoiding
material loss and equipment failure associated with mechanical
protective devices.
*They feature high detection sensitivity for rapid and precise
obstacle detection within the working area.
*The flexibility of installation allows for adjustments based on
actual conditions, suitable for various machine tools and working
environments.
*The adaptability is strong, with applications in different
industrial sectors such as automotive manufacturing, electronics,
aerospace, and more.
*The curtains provide efficient safety protection, forming an
invisible light curtain that monitors and alarms in real-time to
prevent potential hazards.
*Sensitivity is adjustable, catering to safety protection needs in
different environments.
*High reliability and stability are ensured through advanced
optoelectronic technology, allowing normal operation in harsh
environments.
*Easy installation and compact structure facilitate maintenance and
are suitable for a variety of safety protection scenarios.
PRODUCT SPECIFICATIONS
Protective Height: Adjustable from 60 to 1150mm
Beam Gap: Options include 10, 20, 30, or 40mm
Resolution: Varying resolutions of 15, 25, 35, or 45mm
Beams: Available in 4, 6, 8, 10, or 12 beams
Protective Distance: Ranges from 5m to 30m depending on beam specifications
Output Current: Maximum of 200mA
Power Consumption: Less than 5W
Output Signal: NPN/PN options available
Response Time: Less than 5ms
Cross-section: 30*30mm
Operating Voltage: DC10-DC32V
Light Curtain Form: Through-Beam
Dielectric Strength: AC1500V for 60 seconds with no breakdown or flicker
Work Ambient Humidity: Relative humidity at 20°C less than 85%
Anti-light Interference: Incidence Angle greater than 5°
Shell Protection Class: IP65
PRODUCT MATERIALS
The housing of the Safety Light Curtains include materials such as
ABS plastic, PC plastic, or stainless steel, which have certain UV
resistance properties to reduce the impact of sunlight on the
curtains.
PRODUCT APPLICATION
Safety Light Curtains are widely used in industrial automation,
robotics, elevator and automatic door systems, sports and
entertainment venues, commercial and retail, medical equipment, and
transportation systems.
SERVIC and SUPPORT
We provide comprehensive maintenance services to ensure the Safety
Light Curtains remains in optimal condition. Our dedicated support
team is available to assist with any technical queries or service
needs.
